ROADVISION’s RWL500 Series heavy duty LED work lamps are available in 30W or 90W models. Featuring high performance 5W or 10W Cree LED’s and a unique heavy duty shock absorbing mounting system on the 90W model, they are designed to withstand the vibration and harshness of Australia’s toughest environments.
MULTI-VOLT
10-30 VDC
POLYCARB LENS
COLOUR TEMP
WATER & DUST PROOF
OVER/UNDER VOLTAGE PROTECTION
DEUTSCH CONNECTOR
REVERSE POLARITY PROTECTION
3W or 10W CREE LEDS
RADIO INTERFERENCE APPROVED
5 YEAR WARRANTY
RANGE FEATURES
- RWL500 Series heavy duty LED work lamps produce up to 7200lm of instant light output
- Available in 30W or 90W models
- 5W or 10W Cree LED’s produce super white light close to daylight
- Multi-volt 10-30V DC input
- Super low current draw
- 50,000 hour LED lifespan with solid state technology
- Light weight tough die-cast aluminium housing & polycarbonate lens
- Water & dust proof IP67 rated
- Simple 2 wire installation with Deutsch plug
- Over/under voltage, reverse polarity protection & EMI/EMC radio interference approved
- Heavy duty shock absorbing mounting system on RWL590F
DIMENSIONS – RWL530F
DIMENSIONS – RWL590S
RANGE SPECIFICATIONS
| wdt_ID | Part Number | RWL530F | RWL590S |
|---|---|---|---|
| 1 | Description | 5 Series LED Work Lamp 30W Flood | 5 Series LED Work Lamp 90W Spot |
| 2 | Beam Type | Flood Beam | Spot Beam |
| 3 | Lumens Light Output (Effective) | 2700lm | 7200lm |
| 4 | Beam Distance | 45m | 438m |
| 5 | Total Watts | 30W | 90W |
| 6 | Light Source | 6 x 5W CREE LED's | 9 x 10W CREE LED's |
| 7 | Input Voltage | 10-30V DC | 10-30V DC |
| 8 | Current Draw Amps | 2.2A @ 13.8V DC | 6.37A @ 13.8V DC |
| 9 | Dimensions | 100x82x128mm | 135x124x150mm |
| 10 | Wiring | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug |
| 11 | Lux @ 10m | 5 Lux | 480 Lux |
| 12 | Meters @ 1 Lux | 22m | 219m |
| 13 | Meters @ 0.5 Lux | 45m | 438m |
BEAM PATTERN – RWL530F
BEAM PATTERN – RWL590S
