NEXT GENERATION DCX2 SERIES

The Roadvision DCX2 Series are the next generation in dual row curved LED light bars. Producing up to a massive 25920lm of light output, the DCX2 Series deliver brute power and intense light output with a perfect match of advanced optical design and 3W Osram Hi-Lux LEDs. Designed to follow the contour of your vehicle, the curved designed provides greater illuminating coverage, giving you a better field of view in any open road or off road situation. Featuring the latest soft start, PWM dimming and advanced thermal management technology from Roadvision, the DCX2 Series is available in combination beam patterns from 22” to 50” providing a perfect mix of forward penetration and additional roadside illumination from the curved radius housing. Supplied with both low profile adjustable slide mounts and Roadvision’s new 9 position adjustable anti-vibration mounting system, the DCX2 Series also features a new ultra slim 65mm deep housing providing greater mounting flexibility. The DCX2 Series by Roadvision, brute power from the biggest bars in our line-up.

MULTI-VOLT
10-30 VDC

POLYCARB LENS

COLOUR TEMP

WATER & DUST PROOF

OVER/UNDER VOLTAGE PROTECTION

DEUTSCH/ATP CONNECTOR

REVERSE POLARITY PROTECTION

3W OSRAM HI-LUX LEDS

RADIO INTERFERENCE APPROVED

7 YEAR WARRANTY

ADJUSTABLE DUAL MOUNTS

CURVED LIGHT ARC

RANGE FEATURES

  • DCX2 Series dual row curved LED bar lamps produce up to 25920lm of light
  • 3W Osram Hi-Lux LED’s produce super white light close to daylight
  • Curved bar produces a wider beam angle for improved roadside illumination
  • Multi-volt 10-30V DC input & super low current draw
  • 50,000 hour LED lifespan with solid state technology
  • Soft start, PWM dimmable & advanced thermal management technology
  • Light weight tough die-cast aluminium housing & polycarbonate lens
  • Water & dust proof IP67 rated
  • Simple 2 wire installation Deutsch/ATP plug & optional plug & play dimming controller
  • 9 position adjustable anti-vibration end mount system & low profile slide mounts
  • Over/under voltage, reverse polarity protection & EMI/EMC radio interference approved

DIMENSIONS

RANGE SPECIFICATIONS

wdt_ID Part Number RBL6220C RBL6320C RBL6420C RBL6500C
1 Description DCX2 Series 22" Curved Bar 40 LED DCX2 Series 32" Curved Bar 60 LED DCX2 Series 42" Curved Bar 80 LED DCX2 Series 50" Curved Bar 120 LED
2 Beam Type Combo Beam Combo Beam Combo Beam Combo Beam
3 Lumens Light Output (Effective) 10800lm 16200lm 21600lm 25920lm
4 Beam Distance 708m 818m 932m 997m
5 Total Watts 120W 180W 240W 288W
6 Light Source 40x3 Watt Osram LED's 60x3 Watt Osram LED's 80x3 Watt Osram LED's 120x3 Watt Osram LED's
7 Input Voltage 10-30V DC 10-30V DC 10-30V DC 10-30V DC
8 Current Draw Amps 6.7A @ 13.8V 10.0A @ 13.8V 13.3A @ 13.8V 14.1A @ 13.8V
9 Dimensions AxBxC 563x75x78.5mm 818x87x78.5mm 1073x108x78.5mm 1273x128x78.5mm
10 Bar Length 22" (563mm) 32" (818mm) 42" (1073mm) 50" (1273mm)
