Elevate your larger 4WDs and Trucks with Roadvision’s S8 Stealth Series Driving Lights. With contemporary black mounting hardware and innovative dual-colour HALO DRL, these lights feature a stylish bezel-less design. The 24 x 6W Cree LEDs illuminate with an impressive 7937lm per light, projecting a remarkable 768 metres (1086 metres per pair) beam penetration at 1 lux, thanks to Roadvision’s Thermal Management Technology. Built to withstand harsh conditions, the S8 series boasts a robust yet lightweight aluminium housing and a durable polycarbonate lens. Redefine your driving experience with the S8 series’ tough aesthetic and unparalleled lighting prowess. Meanwhile, our 8” light with a low-profile bracket optimises your bull bar space. Embrace the benefits of 9” light output while enjoying a sleeker, more rugged appearance, unlocking your vehicle’s full lighting potential with style and functionality.
THERMAL MANAGEMENT TECHNOLOGY
AMBER OR WHITE HALO
MULTI-VOLT
10-30 VDC
POLYCARB LENS
COLOUR TEMP
WATERPROOF
OVER/UNDER VOLTAGE PROTECTION
REVERSE POLARITY PROTECTION
DEUTSCH CONNECTOR
CREE LEDS
CLASS 3 APPROVED
7 YEAR WARRANTY
RANGE FEATURES
- S8 Stealth Series 8” Driving Light
- Amber or White DRL Halo
- Blackout mounting hardware
- Includes Black cover with DRL Halo window
- 24 x 6W Cree LED’s produce super white light close to daylight
- Multi-volt 10-30V DC input & low current draw
- 50,000 hour LED lifespan with solid state technology
- Thermal Management Technology
- Lightweight tough die-cast aluminium housing & polycarbonate lens
- Water & dust proof IP68 rated
- Over/under voltage, reverse polarity protection
- CISPR25 approved
WHITE HALO DRL
AMBER HALO DRL
ROADVISION COVER
DIMENSIONS
BEAM DIAGRAM
SPECIFICATIONS
| wdt_ID | Part Number | RDL8800C |
|---|---|---|
| 1 | Description | 8” LED Driving Light 10-30V 132W Combination Beam |
| 2 | Beam Pattern | Combination |
| 3 | Maximum Lumens per Light (pair) | 7,937Lm (15,874lm) |
| 4 | Maximum Lux @ 10m per Light (pair) | 5,900Lx (11,800lx) |
| 5 | Maximum Beam Distance @ 1lx per Light (pair) | 768m (1,086m) |
| 6 | Maximum Beam Distance @ 0.5lx per Light (pair) | 1,086m (1,536m) |
| 7 | Input Voltage | 10-30VDC |
| 8 | Maximum Watts | 132W |
| 9 | Number of LEDS | 24 x 6W Osram |
| 10 | Current Draw @ 13.8V | 9.6 Amps |
| 11 | Lens Construction | Polycarbonate |
| 12 | Housing Construction | Die-Cast Aluminium |
| 15 | Dimensions AxBxC | 232 x 83 x 218mm |
| 16 | Wiring Driving Lights | 2 Pin Deutsch Plug, Red - Driving Light +Ve, Black - Driving Light -Ve |
| 17 | Wiring DRL Halo | Blue - Amber Position Light +Ve, White - White Position Light +Ve |
