Making performance and productivity count… Original equipment quality head lamp systems combined with state-of-the-art LED technology. ROADVISIONās new high performance head lamps are manufactured with LEDās (Light Emitting Diodes) rather than regular halogen light bulbs. These high performance lamps are designed to be more efficient with a robust construction offering environmental sustainability with no maintenance required. Roadvisionās LED head lamps are ideal for original equipment manufacturers and aftermarket retrofitting to modern styled trucks, buses and specialist vehicles. Roadvisionās LED head lamps provide: reduced vehicle downtime and running costs, reduced engine, alternator and battery wear, zero maintenance for the life of the vehicle*, reduced fuel consumption, engine load and CO2 emissions, greater visibility and reduced road glare, greater durability and endurance and a five-year limited warranty. ā¢ Energy Efficient ā¢ Environmentally Friendly ā¢ Durable & Long Lasting ā¢ No Maintenance Costs ā¢ No Downtime Costs.

24VDC INPUT

POLYCARB LENS

COLOUR TEMP

IP69K WATER & DUST PROOF

OVER/UNDER VOLTAGE PROTECTION

REVERSE POLARITY PROTECTION

ADR/ECE APPROVED

RADIO INTERFERENCE APPROVED

5 YEAR WARRANTY
RANGE FEATURES
- Instant light output surpassing 24 volt 70 watt halogen
- Produces a super white light temperature similar to daylight
- Super low power consumption of less than 0.8 amps
- 100,000 hour LED life span with solid state technology
- Zero maintenance for the life of the vehicle*
- Light weight die-cast aluminium housing
- Unbreakable polycarbonate lens
- IP69K ingress protection (submersible to 3m)
- Completely sealed from dust and water
- Supplied pre-wired with external driver box included
- Direct replacement for existing halogen lamps
- ADR/ECE approved
- 12V available on request
DIMENSIONS
RV90HB

RV90LB

FRONT & SIDE VIEWS
RV90HB Front & Side View

RV90LB Front & Side View

RANGE SPECIFICATIONS
wdt_ID | Part Number | RV90HB | RV90LB |
---|---|---|---|
1 | Description | Head Lamp LED High Beam 90mm | Head Lamp LED Low Beam 90mm |
2 | Beam Type | High Beam with Park | Low Beam |
3 | Lumens Light Output (Effective) | 1000lm | 700lm |
4 | Total Watts | 23W | 17W |
5 | Light Source | High Powered LED Modules 15W 4-chip plus 7.4W 2-chip | High Powered LED Modules 15W 4-chip |
6 | Input Voltage | 24V DC | 24V DC |
7 | Current Draw Amps | 0.8A @ 28.5V | 0.6A @ 28.5V |
8 | Dimensions | 141.5x109.5mm | 140.2x130.5mm |
9 | CTA-Approval | CTA-061124 | CTA-061123 |
