The Roadvision SR2 Series LED bar lights are proof size doesn’t matter. Measuring only 52mm tall, the SR2 Series defies its compact size producing beam penetration reaching as far as 1200m with a perfect match of advanced optical design and the latest 3W Osram Hi-Lux LEDs. Featuring the latest soft start, PWM dimming and advanced thermal management technology from Roadvision, the SR2 Series is available in spot, flood & combo beams from 5” to 50”. Supplied with both low profile adjustable slide mounts and Roadvision’s new 6 position adjustable anti-vibration mounting system, the SR2 Series are the ideal choice for applications where space is limited. The SR2 Series by Roadvision, punching above its size with superior beam penetration.
MULTI-VOLT
10-30 VDC
POLYCARB LENS
COLOUR TEMP
WATER & DUST PROOF
OVER/UNDER VOLTAGE PROTECTION
DEUTSCH CONNECTOR
REVERSE POLARITY PROTECTION
3W OSRAM HI-LUX LEDS
RADIO INTERFERENCE APPROVED
7 YEAR WARRANTY
ADJUSTABLE DUAL MOUNTS
RANGE FEATURES
- SR2 Series single row LED bar lamps produce up to 10530lm of instant light output
- Available in 5” to 50” models
- 3W Osram Hi-Lux LED’s produce super white light close to daylight
- Multi-volt 10-30V DC input & super low current draw
- 50,000 hour LED lifespan with solid state technology
- Soft start, PWM dimmable & advanced thermal management technology
- Light weight tough die-cast aluminium housing & polycarbonate lens
- Water & dust proof IP67 rated
- Simple 2 wire installation with Deutsch plug & optional plug & play dimming controller
- 6 position adjustable anti-vibration end mount system & low profile slide mounts
- Over/under voltage, reverse polarity protection & EMI/EMC radio interference approved
DIMENSIONS
RANGE SPECIFICATIONS
| wdt_ID | Part Number | RBL1050F | RBL1090S | RBL1210C | RBL1320C | RBL1400C | RBL1500C |
|---|---|---|---|---|---|---|---|
| 1 | Description | SR2 Series 5" Bar 3 LED | SR2 Series 9" Bar 6 LED | SR2 Series 21" Bar 15 LED | SR2 Series 32" Bar 24 LED | SR2 Series 40" Bar 30 LED | SR2 Series 50" Bar 39 LED |
| 2 | Beam Type | Flood Beam | Spot Beam | Combo Beam | Combo Beam | Combo Beam | Combo Beam |
| 3 | Lumens Light Output (Effective) | 810lm | 1620lm | 4050lm | 6480lm | 8100lm | 10530lm |
| 4 | Beam Distance | 63m | 610m | 716m | 938m | 1080m | 1200m |
| 5 | Total Watts | 9W | 18W | 45W | 72W | 90W | 117W |
| 6 | Light Source | 3x3 Watt Osram LED's | 6x3 Watt Osram LED's | 15x3 Watt Osram LED's | 24x3 Watt Osram LED's | 30x3 Watt Osram LED's | 39x3 Watt Osram LED's |
| 7 | Current Draw Amps | 0.5A @ 13.8V | 1.2A @ 13.8V | 3.2A @ 13.8V | 5.2A @ 13.8V | 6.6A @ 13.8V | 8.7A @ 13.8V |
| 8 | Voltage Input | 10-30V DC | 10-30V DC | 10-30V DC | 10-30V DC | 10-30V DC | 10-30V DC |
| 9 | Dimensions AxBxC | 140x59x52mm | 236x59x52mm | 524x59x52mm | 812x59x52mm | 1004x59x52mm | 1292x59x52mm |
| 10 | Bar Length | 5" (140mm) | 9" (263mm) | 21" (524mm) | 32" (812mm) | 40" (1004mm) | 50" (1292mm) |
| 11 | Wiring | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug | 2 Pin Deutsch Plug |
| 12 | Lux @ 10m | 10 Lux | 930 Lux | 1885 Lux | 3000 Lux | 3480 Lux | 5400 Lux |
| 13 | Meters @ 1 Lux | 32m | 305m | 358m | 469m | 540m | 600m |
| 14 | Meters @ 0.5 Lux | 63m | 610m | 716m | 938m | 1080m | 1200m |
3 POINT ISOLATION MOUNT Signature red neoprene shock and vibration absorbers for ultimate performance and stability.
ADJUSTABLE MOUNTING SYSTEM Adjustable side mounts feature 6 height settings using cleaver rubber cam isolators. Designed with 2 slots, each slot can be top, centre or bottom mounted allowing for precise positioning.
Adjustable slide mounts
