Upgrade your vehicle’s lighting with the Roadvision Dynamilux Series 8” LED Driving Lights. Designed for style and performance, it features a dual-colour dynamic start-up DRL that adds a modern touch while improving daytime visibility. With a combination beam pattern, these lights deliver an impressive 1LX @ 834 metres per pair and a crisp 5700K colour temperature for exceptional clarity during nighttime driving. Built tough with an IP67 rating for water and dust resistance and backed by a 7-year warranty, the Dynamilux Series is made to last. Each light comes with a protective cover featuring DRL windows, offering extra durability without compromising functionality. Perfect for drivers who demand reliability, performance and style in one sleek package.
THERMAL MANAGEMENT TECHNOLOGY
DYNAMIC DRL
MULTI-VOLT
10-30 VDC
POLYCARB LENS
ALUMINIUM HOUSING
COLOUR TEMP
WATERPROOF
DEUTSCH CONNECTOR
OSRAM LEDS
RADIO INTERFERENCE APPROVED
7 YEAR WARRANTY
RANGE FEATURES
- RDL7800 Series 8” Driving Light
- Amber or White Dynamic start-up DRL
- Blackout mounting hardware
- Includes Black cover with DRL windows
- 18 x 10W Osram LED’s with a crisp 5700K colour temperature
- 1LX @ 834 metres per pair
- Multi-volt 10-30V DC input & low current draw
- 50,000 hour LED lifespan with solid state technology
- Thermal Management Technology
- Lightweight tough die-cast aluminium housing & polycarbonate lens
- Water & dust proof IP67 rated
- Over/under voltage, reverse polarity protection
- EMI/EMC radio interference approved
PROTECTIVE COVER
WHITE DYNAMIC DRL
AMBER DYNAMIC DRL
DIMENSIONS
BEAM DIAGRAM
POWER MODE INSTRUCTIONS
- The device is currently in low-power mode.
- During startup, it briefly enters high-power mode due to the control chip initialisation, then switches to low-power mode.
- To switch permanently to high-power mode:
– Turn the lamp on and off 4 times within 50 seconds (about 1–2 seconds between each cycle). - Once set to high-power mode, the device will stay in that mode unless the 4-cycle toggle is repeated.
SPECIFICATIONS
| wdt_ID | Part Number | RDL7800C |
|---|---|---|
| 1 | Description | 8” LED Driving Light 10-30V 180W Combination Beam |
| 2 | Beam Pattern | Combination |
| 3 | Maximum Lumens per Light (pair) | 9,900lm (19,800lm) |
| 4 | Lux @ 10m per Light (pair) | 3,480lx (6,960lx) |
| 5 | Beam Distance @ 1lx per Light (pair) | 590m (834m) |
| 6 | Beam Distance @ 0.5LX per Light (pair) | 834m (1,180m) |
| 7 | Input Voltage | 10-30VDC |
| 8 | Maximum Watts | 180W |
| 9 | Number of LEDS | 18 x 10W Osram |
| 10 | Current Draw @ 13.8V | 10.2 Amps |
| 11 | Lens Construction | Polycarbonate |
| 12 | Housing Construction | Die-Cast Aluminium |
| 15 | Wiring | 4 Pin Deutsch Plug Red – Positive Black – Negative Yellow – Amber DRL White – White DRL |
| 16 | Dimensions AxBxC | 220 x 80 x 229mm |
